CompactFlash Card Connector - Express B Type - Push Push

• CF Express Card Host Connector, B Type, 21Pin, R/A SMT Push Push, With Two Posts

  • Dimensions: 34.45x36.8x6.1(at maximum)
  • P/N: 139F40-NAATG310
• Material & Finish:

  • Housing & Sloder: High Temperature Thermoplastic With Glass Fiber Filler, UL94V-0 Rated, Coloer In Black
  • Metal Shell: Stainless teel SUS 304, Gold Flash Plated On Solder Area
  • Contact: Copper Alloy, 15u" Gold Plating On Contact Area, Tin Plated On Solder Area, Nickel Under Plated Overall
  • Spring: Paino thread
  • Crank: Stainless Rod SUS 304
  • Card Lock: Stainless Steel SUS 304

  Electrical Specification

  • Current: DC 0.5A
  • Voltage: DC 5V
  • Dielectric Withstanding Voltage: 500V AC RMS For One Minute

  Operation Temperature: -25°C TO +85°C
